StorEdge Network 2GB FC Switch-8

Codename: Viper-2

Option SG-XSW8-2GB

370-5657 540-5554
QLogic SANbox2A-8 FRU Assembly

Front View

Parts Breakdown

PART # DESCRIPTION
595-6742
180-1949
340-7668
370-7669
340-7670
340-7673
340-7676
540-4558
540-5554
330-2305
370-5657
Network 2GB FC Switch-8
AC Y Power Cord (Option X319YA)
Mounting Tray
Right Mounting Rail
Left Mounting Tray
Tray Adapter Bracket
Rear Bracket
2U Vented Panel
Switch Assembly/FRU
Hub Retainer
8-Port Switch

Notes

  1. Forced PROM mode sets the default IP address 10.0.0.1.

References

  1. SAN 4.0 Release Guide to Documentation, 816-4470.
  2. Sun StorEdge[tm] SAN 4.0 Release Field Troubleshooting Guide, 816-6580
  3. SANbox2-8 Installation and User's Manual, Qlogic 59042-00.
  4. SANbox2 Switch Management User's Manual, Qlogic 59022-03.
