Seagate ST336704FC (36.4GB)

3 1/2" 10000 RPM FC-AL

E3500 / A28 / A29 / A35
StorEdge A5000 / StorEdge A5100 / StorEdge A5200
StorEdge T3 / StorEdge T3+
Sun Fire V480 / Sun Fire V880 / Netra 20

Options 6706 / 6714 / 6724 / 6751 / 6819

390-0035 390-0056
1" Height
Cheetah 36LP
Assy 540-4525
Assy 540-5698		 1" Height
Cheetah 36LP
Assy 540-4367
540-4367 540-4525 540-5698
T3 FRU
w Bkt 540-4303		 Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269		 Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269

Notes

  1. Drives 390-0035 and 390-0056 are the same Seagate model number.
  2. Drives 390-0035 and 390-0056 are not interchangeable because they have different firmware and different mode sense data.
  3. Netra 20 36GB Assembly 540-5698 (released in December 2002) does not include 390-0137.
  4. Solaris 2.5.1 Patch 105310-05, 2.6 Patch 105375-10, or <2.7 11/99 Patch 107469-08 is required for non-boot disk drives.
  5. Solaris 2.5.1 and 2.6 boot drives require the workaround described in FIN I0645-1. No workaround is available for Solaris <2.7 11/99.

Reference:

36 Gbyte 10000 rpm Disk Drive Specifications, 806-1491.
